Features
3“Auto” function: Auto sample loading & Auto rotary scanning & Auto sample mixing
Reliable performance: Reliable performance: Smart counting mode ensures higher accuracy for low-WBC and low-PLT samples, while the dedicated BASO channel delivers real 5-part analysis
Minimal maintenance by using imported key components
Easy operation with 10.4-inch touch screen and intuitive software
Effortless clinical testing: Minimum sample volume 15 µl, 80T/H, 28 reportable parameters + 8 research parameters, 4 scattergrams + 2 histograms, covering most clinical needs.
Cost-effective: Only need 2 lyses+1 diluent
CE certificated
Specification
Throughput: 80 samples/hour
Principle: Tri-angle laser scattering and sheath flow for WBC; Impedance for RBC/PLT; Colorimetry for HGB
Parameters: 28 reportable parameters + 8 research parameters; 4 scattergrams + 2 histograms
Sample modes: Whole blood, capillary, prediluted, smart counting
Sample volume: Whole blood/Smart counting mode: 15μL(Open vial sampling) or 20μL(auto-loading); Pre-diluted: 20μL (Open vial sampling)
Screen size: 10.4-inch touch screen
Interface: 4 USB, 1 network port, bi-directional LIS
Dimension: 685×580×560mm
Weight: 55 kg
