Features
Reliable performance
Ø Smart counting mode ensures higher accuracy for low-WBC / PLT samples
Ø Dedicated BASO channel delivers real 5-part analysis
3 “Auto”
Ø Auto sample loading
Ø Auto rotary scanning
Ø Auto sample mixing
Minimal maintenance
Ø Imported key components (Valve: SMC, Pump: KNF, etc.), better stability and lower failure rate
Easy operation
Ø 10.4-inch touch screen
Effortless clinical testing
Ø 15 μL blood/test
Ø 28 + 8 parameters
Ø 4 scattergrams + 2 histograms
Cost-effective
Ø 2 lyses + 1 diluent
Specification
| Throughput: | 80 T/H |
| Principle: | Tri-angle laser scattering and sheath flow for WBC; Impedance for RBC/PLT; Colorimetry for HGB |
| Parameters: | 28 reportable parameters + 8 research parameters; 4 scattergrams + 2 histograms |
| Sample modes: | Whole blood, capillary, prediluted, smart counting |
| Sample volume: | Whole blood/Smart counting mode: 15μL(Open vial sampling) or 20μL(auto-loading); Pre-diluted: 20μL (Open vial sampling) |
| Screen size: | 10.4-inch touch screen |
| Interface: | 4 USB, 1 network port, bi-directional LIS |
| Dimension: | 685×580×560mm |
| Weight: | 55 kg |
| Certification: | CE |
